GL-50D
Glead
Availability: | |
---|---|
Quantity: | |
Product Introduction
Automatic sense tableware washing system,automatic standby when there is no dish basket,energy saving and consumption reduction.
The transmission system is safe and efficient,with automatic overload protection,and two transmission speed can be selected by adjusting the gear.
Stainless steel detachable washing arm,convenient for cleaning and maintenance.
The main washing arm has an anti-blocking nozzle,uniform water volume,and stable washing effect.
Imported water pumps and major electrical accessories,safe and reliable.The water inlet is equipped with a pressure reducing valve to adjust the water pressure stably.
All stainless steel material,durable.
Built-in liquid dispenser can be used to save space
Pre-wash and drying function modules can be added to meet customer needs.
Fully enclosed bottom plate,insect and rodent prevention.
Three-layer water curtain at the entrance to prevent splashing.
Patented energy-saving module,waste heat recovery energy saving 35%(Optional)
Patented startup without preheating.
Specification
Type | Undercounter Diswasher | Hood-type Diswasher | Double Rack Hood-Type | New model hood-type | ||
Model | GL-UD50(380V) | GL-UD50(220V) | GL-HD60 | GL-HD60E | GL-HD120 | GL-HD60D |
Product Size(mm) | 570x620x780 | 570x620x780 | 700X815X1440 | 700x815x1440 | 1266x815x1440 | 700x815x1500 |
Package Size(mm) | 660x650x940 | 660x650x940 | 740X850X1560 | 740X850X1560 | 1306x850x1560 | 740x850x1620 |
N.W/G.W(KG) | 65/75 | 65/75 | 105/120 | 105/120 | 190/220 | 110/125 |
Vol/Frequency (V/Hz) | 380V/50Hz/3P | 220V/50Hz | 380V/50Hz/3P | 380V/50Hz/3P | 380V/50Hz/3P | 380V/50Hz/3P |
Rated Power(kW) | 7.4 | 5.4 | 15.8 | 6.8 | 25.7 | 9.8 |
Washing Heating Power(kw) | 1 | 1 | 3 | 1.5 | 3x2 | 3 |
Rinse Heating Power(kw) | 6 | 4 | 12 | 4.5 | 18 | 9 |
Washing water pump(kW) | 0.37 | 0.37 | 0.75 | 0.75 | 0.75*2 | 0.75 |
Washing Temperature(°c) | 55-60 | 55-60 | 55-60 | 55-60 | 55-60 | 55-60 |
Rinse Temperature(°c) | 82-90 | 82-90 | 82-90 | 82-90 | 82-90 | 82-90 |
Washing Capacity (basket/hour) | 60 | 60 | 60 | 60 | 120 | 60 |
Water comsumption (L/basket) | 2.3 | 2.3 | 2.3 | 2.3 | 2.3 | 2.3 |
Product Advantage
Reduce Labor Costs;
Improve Efficiency of washing and enhance overall service;
Enhance hygiene&safety;
Reduce workload intensity.
Product Uses
Chain Restaurants
Supermarkets
Hotels
Food Factory
School
